167V12 Hammond Transformer115V 50Hz/60Hz 20A

Roll over image to zoom
  • Buy 10 for $98.20 each and save 5%
$102.91
In Stock
OR


  • Primary: 115V 50/60Hz

  • Secondary (Full Load): 12.6V

  • Power - Max: 252VA


MFR: Hammond MFG
SKU: 167V12


Be the first to review this product


Details

167V12 Hammond Transformer115V 50Hz/60Hz 20A

  • Series: 167
  • Type: Laminated Core
  • Voltage - Primary: 115V
  • Voltage - Secondary (Full Load): 12.6V
  • Current - Output (Max): 20A
  • Primary Winding(s): Single
  • Secondary Winding(s): Single
  • Center Tap: Yes
  • Power - Max: 252VA
  • Mounting Type: Chassis Mount
  • Termination Style: Wire Leads
  • Size / Dimension: 95.25mm L x 114.30mm W
  • Height - Seated (Max): 115.82mm
  • Voltage - Isolation: 2000Vrms
  • Weight: 8.4 lbs (3.8 kg)

MFR: Hammond

See Data Sheet

Additional Information

Featured Product No
Made in the USA No
Manufacturer No
NOS No
Call For Price No
Manufacturer Name HAMMOND
