Most resistors are color coded with multiple bands to identify the resistance value and the tolerance. While actually measuring the resistance before using it is a good idea, it's also a good idea to know what the resistance is supposed to be. Resistors (especially carbon composition) can drift in their actual resistance. Keep a stock of fresh resistors on hand. Use the following Standard EIA color code tables to identify resistors, or you can calculate the values on your your resistors using our handy resistance calculator.
4 Band Resistors
| Color | 1st Band (1st Figure) | 2nd Band (2nd Figure) | 3rd Band (Multiplier) | 4th Band (Tolerance) |
|---|---|---|---|---|
| Black | 0 | 100 | ||
| Brown | 1 | 1 | 101 | ±1% |
| Red | 2 | 2 | 102 | ±2% |
| Orange | 3 | 3 | 103 | |
| Yellow | 4 | 4 | 104 | |
| Green | 5 | 5 | 105 | ±0.5% |
| Blue | 6 | 6 | 106 | ±0.25% |
| Violet | 7 | 7 | 107 | ±0.1% |
| Grey | 8 | 8 | 108 | ±0.05% |
| White | 9 | 9 | 109 | |
| Gold | 10-1 | ±5% | ||
| Silver | 10-2 | ±10% |
5 Band Resistors
| Color | 1st Band (1st Figure) | 2nd Band (2nd Figure) | 3rd Band (Multiplier) | 4th Band (Tolerance) | 5th Band (Tolerance) |
|---|---|---|---|---|---|
| Black | 0 | 0 | 100 | ||
| Brown | 1 | 1 | 1 | 101 | ±1% |
| Red | 2 | 2 | 2 | 102 | ±2% |
| Orange | 3 | 3 | 3 | 103 | |
| Yellow | 4 | 4 | 4 | 104 | |
| Green | 5 | 5 | 5 | 105 | ±0.5% |
| Blue | 6 | 6 | 6 | 106 | ±0.25% |
| Violet | 7 | 7 | 7 | 107 | ±0.1% |
| Grey | 8 | 8 | 8 | 108 | ±0.05% |
| White | 9 | 9 | 9 | 109 | |
| Gold | 10-1 | ±5% | |||
| Silver | 10-2 | ±10% |
-
1026AS200KDS Carborundum 70 Watt 20 Ohm 10% Non-inductive Ceramic Resistor (Pull)
$29.91 -
888SP100K Carborundum 190 Watt 10 Ohm 10% Non-inductive Ceramic Resistor (Pull)
$34.91 -
HL80-04Z-64J Vishay Wirewound Resistor (NOS)
$19.91 -
0962 Ohmite Adjustable Wirewound Resistor (NOS)
$19.91 -
-
887SP Carborundum Co. 150 Watt, 25 Ohm Ceramic Resistor (Pull)
$19.91 -
887AS121JDS Carborundum 50 Watt, 120 Ohm 5% Non-inductive Ceramic Resistor (Pull)
$89.95 -
218SP-28 Carborundum 60 Watt 50 Ohm Non-inductive Ceramic Resistor (Pull)
$44.91 -
-
50R00J Ohmite, 50Ω 50w 5% (NOS)
$11.50
