NOTE: Attenuation expressed in decibels of relative power.
A 3 dB pad reduces power to one half, 6 dB to one fourth, 10 dB to one tenth, 20 dB to one hundredth, 30 dB to one thousandth and so on. For voltage you double the dBs so for example 6 dB is half in voltage.
EXAMPLE: Calculating 50 Watt Attenuator into dB:
3db: 50 x 0.50 = 25 watt; 6db: 50 x 0.25 = 12.5 watt; 10db: 50 x 0.10 = 5 watt; 20db: 50 x 0.01 = 0.5 watt; 30db: 50 x 0.001 = 0.05 watt; 40db: 50 x 0.0001 = 0.005 watt.
These parts are clean used parts tested to factory spec. Picture is for reference. Cosmetic condition will vary slightly.
- VSWR: 1.35 Maximum
- Average Power: 20 Watts
- Attenuation: 30dB Nominal
- Peak Power: 1 Kilowatt
Clean used * No longer available for export
Application Design: Transmission Line
Body Surface Treatment: Silver Plated, Qq-S-365
Input Impedance Rating In Ohms: 50.0
Output Impedance Rating In Ohms: 50.0
Power Rating: 4.0 Watts Average
RF Signal Attenuation In Decibels: 3.0
Voltage Standing Wave Ratio Frequency Range: +0.0/+2.5 Gigahertz
Used * Clean * No longer available for export
MFR: Microlab / FXR
SKU: AA-03N-PMade in the USA
Frequency: 2.5 GHz
Attenuation accuracy from 50-800MHz is +/-0.5dB Max
VSWR from 50-800MHz is 1.15:1 Max
Input Power 2 Watts @ 25oC
Peak Power 250 Watts Maximum
Impedance: 50 Ohms
Operating Temp Range: -65oC to +125oC
Length: 1.76 inches
Outside Diameter: 0.62 inches
New Old Stock * No longer available for export
SKU: 2N-03-320Made in the USA
