Power Transformers

Heavy Duty Industrial-Grade Transformer

GB5226

GB5226  Heavy industrial-grade Transformer, designed for operation on 220V, 50-60 Hz. Because of the the 50 Hz rating, operation on 240 VAC 60 Hz will yield 20% increase in VA rating (450 VA), and 9% increase in terminal voltage. Using Transformer in Voltage Doubler circuit will yield 600 VDC @ 0.5A on 120 VAC, and 1200 VDC @ 0.4A on 240 VAC (ICAS). Ideal for sweep tube, or three 811A amplifier. Quality construction includes barrier block and cover.

Size: 4 3/4”W x 4 1/4”D x 4 3/4” H

Shipping Weight: 12.5 lbs.

Part Number: GB5226



Power / Filament Transformer

Excellent Quality .
Mfg. by MagneTek Triad

F-271U Power Transformer




•   Primary 115V 50/60 Hz
•   Secondary 40 VCT @ 2A

Size: 2 3/4” x 2 1/2” x 3 3/8”
Shipping Weight: 4 lbs.

Part Number: F-271U



Excellent Quality .
Mfg. by MagneTek Triad

F-41X Power Transformer




•   Primary 115V  60 Hz
•   Secondary 25.2 VCT @ 2A

Size: 4” x 2 1/4” x 2 5/8”
Shipping Weight: 3 lbs.

Part Number: F-41X

Excellent Quality .
Mfg. by MagneTek Triad
F-255X Transformer




•   Primary 115V  60 Hz
•   Secondary 20 VCT @ 2A

Size: 4” x 2 1/4” x 2 5/8”
Shipping Weight: 3 lbs.

Part Number: F-255X




Isolation Transformer
Mfg. by Triad-Ultrad

N73A Power Transformer


Size: 3 7/8 ” x 3 1/4” x 3 3/4 ”
Shipping Weight: 6.2 lbs.

Part Number: N-73A

List  Grid

per page
Set Descending Direction

  1. ECA1082 Step Down Transformer, 240vac Primary, 120vac Secondary, 500va Removed from Henry 3000D

    ECA1082 Step Down Transformer, 240vac Primary, 120vac Secondary, 500va Removed from Henry 3000D

    Regular Price: $199.95

    Special Price $179.95

    ECA1082 Step Down Transformer, 240vac Primary, 120vac Secondary, 500va MFR: ECA - Anaheim

    This transformer was removed from a working Henry 3000D RF Power Generator amplifier.  In excellent condtion - Like New.

    Size: 4-3/8" Long x 5-3/8" High x 5" wide, Weight: 17.45 lbs

    Made in USA, Limited Quantity Available, Not Available for Export

    Made in the USA

  2. ECA5024 HV Swinging Choke Transformer, 1 amp Continuous Removed from Henry 3000D

    ECA5024 HV Swinging Choke Transformer, 1 amp Continuous Removed from Henry 3000D

    Regular Price: $279.95

    Special Price $249.95

    Out of stock

    ECA5024 HV Swinging Choke Transformer, 1 amp Continuous (Removed from Henry 3000D), MFR: ECA

    This HV Choke transformer was removed from a working Henry 3000D RF Power Generator amplifier.  In excellent condtion - Like New.

    Size: 5-3/8" Long x 6-1/2" High x 6-1/2" wide, Weight: 35.65 lbs

    Made in USA, Limited Quantity Available, Not Available for Export

    Made in the USA

  3. ECA26028 High Voltage Transformer, 208/230vac 3 Phase, Primary, 6000vac 3amp Secondary, Removed from Henry 3000D

    ECA26028 High Voltage Transformer, 208/230vac 3 Phase, Primary, 6000vac 3amp Secondary, Removed from Henry 3000D

    $589.95

    ECA26028 High Voltage Transformer, 208/230vac 3 Phase, Primary, 6000vac 3amp Secondary, Removed from Henry Electronics 3000D

    This transformer was removed from a working Henry 3000D RF Power Generator.  In excellent condtion - Like New.
    Size: 12" Long x 8" High x 10" wide, Weight: 120 lbs  (Must ship by Truck Freight)
    Made in USA, Limited Quantity Available, Not Available for Export

    Made in the USA
  4. F-29U Triad Filament Transformer 115v 50/60 Hz

    F-29U Triad Filament Transformer 115v 50/60 Hz

    $45.91

    • Voltage - Primary: 115V
    • Voltage - Secondary (Full Load): 10V, 11V, 12V
    • Current - Output (Max): 11A
    • Power - Max: 132VA
    • Voltage - Isolation: 3000Vrms
    • Weight: 6.5 lbs (2.9 kg)

    MFR: Triad Magnetics
    SKU: F-29U

    See Data Sheet

  5. 104415 Hammond Control Transformer 1kv 240x480 (NOS)

    104415 Hammond Control Transformer 1kv 240x480 (NOS)

    Call for Price
    1-800-RFPARTS (1-800-737-2787)

    New Old Stock * No longer available for export
    MFR: Hammond
    SKU: 104415


  6. ECA5027 HV Swinging Choke Transformer, 15-8 Henry, 1.5A Removed from Henry 3000D

    ECA5027 HV Swinging Choke Transformer, 15-8 Henry, 1.5A Removed from Henry 3000D

    $269.95

    ECA5024 Swinging Choke Transformer, 15-8 Henry, 1.5A Continuous (Removed from Henry 3000D), MFR: ECA

    This High Voltage Choke Transformer was removed from a working Henry 3000D RF Power Generator Amplifier.

    It is in like-new, excellent condtion

    Size: 5.5" Long x 6-1/2" High x 8" wide, Weight: 46 lbs

    Limited Quantity Available  No longer available for Export

    Made in the USA
  7. F-213Z Triad Power Transformer 115V / 230V 50/60Hz

    F-213Z Triad Power Transformer 115V / 230V 50/60Hz

    $20.91

    The F-213Z transformer is part of a series of Triad Control transformers that have secondary voltages that are commonly utilized in various electronic, electro-magnetic and electrical control systems.

    • Type: Laminated Core
    • Voltage - Primary: 115V, 230V
    • Voltage - Secondary (Full Load): Parallel 24V, Series 48V
    • Current - Output (Max): Parallel 2A, Series 1A

    MFR: Triad Magnetics
    SKU: F-213Z
