Attenuators
Please choose from the following ATTENUATOR Sub-Catagory choices:
FIXED |
ROTARY |
TOGGLE |
NOTE: Attenuation expressed in decibels of relative power.
A 3 dB pad reduces power to one half, 6 dB to one fourth, 10 dB to one tenth, 20 dB to one hundredth, 30 dB to one thousandth and so on. For voltage you double the dBs so for example 6 dB is half in voltage.
EXAMPLE: Calculating 50 Watt Attenuator into dB:
3db: 50 x 0.50 = 25 watt; 6db: 50 x 0.25 = 12.5 watt; 10db: 50 x 0.10 = 5 watt; 20db: 50 x 0.01 = 0.5 watt; 30db: 50 x 0.001 = 0.05 watt; 40db: 50 x 0.0001 = 0.005 watt.
-
50F-003 JFW Type-N Male / Type-N Female 3dB 1 Watt Fixed Attenuator
$14.91 As low as: $14.16 -
-
660-8-1 Fixed Attenuator, SMA Male/Female, DC-4 GHz, 8dB, Meca
$15.95 -
SAT-6 Fixed Attenuator, SMA Male/Female, DC-1500 MHz, 6dB, Mini Circuits
$9.95 -
SAT-3 Fixed Attenuator, SMA Male/Female, DC-1500 MHz, 3dB, Mini Circuits
$9.95 -
6N5W-15 API / Inmet Fixed Attenuator Type N Male/N Female 5 Watts 15dB DC 6 GHz
$61.91 -
5AMFN-6 Fixed Attenuator, 5w 6dB, Type-N Male / Female, DC-4 GHz, Bird
$76.00 -
2-A-MFN-10 Bird Attenuator 2 watt 10dB Type-N Male-Female
$65.00 -
18A-10 API / Inmet Fixed Attenuator SMA Male/Female DC-18 GHz 10dB
$35.91 -
