Relays
Please choose from the following RELAY Sub-Catagory choices:
|
|
COAX RELAYS (VARIOUS MANUFACTURERS)
|
|
|
|
|
|
|
|
|
|
| RELAY SOCKETS
|
|
|
|
|
|
-
RB1D Jennings SPDT, 28vdc 265 ohm, 12kv Flange Mount(Pull)
$89.95 -
7609820P5 Jennings Vacuum Relay Assembly (Pull)
$449.91Similar to Jennings 9975761
- FSN Assembly # 5945-849-0754
- Switch Type: R1
- Peak Test Voltage: 50KV
- RMS Amps: 50 Amps
- Insulated Peak Test Voltage: 20KV
- Solenoid Voltage: 115 VAC
- Size: 12" Long x 3" wide x 3.5" high
Clean used * No longer available for export
MFR: Jennings Radio Manufacturing Corporation
SKU: 7609820P5-PMade in the USA -
-
RF62/26S-P Jennings Vacuum Relay, 26.5vdc, 290Ω (Pull)
$79.95Out of stock
-
RS8-26N360 Jennings Vacuum Relay, SPST 26.5vdc, 120Ω, 28kv (Pull)
$295.00 -
RF61-26N915 Jennings Vacuum Relay 26.5vdc 290Ω (NOS)
$119.91 -
-
RC43E6051H44 Jennings Coaxial Vacuum Relay with LC Female Connectors (Pull)
$414.91 -
Vacuum Variable Capacitor Assembly with Jennings UCSXF-1200-15S and Kilovac H9/S21 Relay -15-1200pf 15kv Peak (Pull)
$839.91This replacement assembly from older Military equipment includes the following items:
- UCSXF-1200-15S Jennings Vacuum Capacitor
- H9/S21 Kilovac Vacuum Relay
- FYLM 73100-16 Barber Coleman Servo Motor with reduction gear drive
- 9 pin connector assembly
- Aluminum mounting assembly / Case.
Capacitance: 15-1200 pf
Voltage Rating: 15 KVp
Current Rating: 65 amps
Important Dimensions
Max Length 10.0 in / 254.0 mm (including shaft) Capacitor; 12 in Long x 4.5 in Wide x 6 in High-- Full Assembly
Max Diameter 4.32 in / 109.73 mm
Weight 8.75 lbs (Full Assembly)
Mounting Full assembly has mounting screws for complete mounting
Shaft Round 1/4"MFR: Jennings / Kilovac
Used * No longer available for export
New assemblies that have not been in service.
SKU: 80063 ASSY A3026408Made in the USA -
RS8-115S Vacuum Relay, SPST 115vdc, 2280Ω, 28kv, Jennings (NOS) 5945-00-900-3209
$395.00
