Switches

Please choose from the following SWITCH Sub-Catagory choices:

BAND

BAND SWITCH

COAX

COAX SWITCH

BIRD COAX

BIRD COAX SWITCH

 FOOT

FOOT SWITCH

PUSH BUTTON

PUSH BUTTON

ROCKER

ROCKER SWITCH

ROTARY

ROTARY SWITCH

SLIDE

SLIDE SWITCH



 THERMAL

THERMAL SWITCH



TOGGLE

TOGGLE

SURFACE MOUNT

SURFACE MOUNT SWITCH



List  Grid

per page
Set Descending Direction
  1. C10 Kraus & Naimer Rotary 3-Position Rotary Switch 600vac 12 amp (Pull)

    C10 Kraus & Naimer Rotary 3-Position Rotary Switch 600vac 12 amp (Pull)

    $109.91

    • Rotary Switch
    • 12 amperes
    • 600 vac
    • 300 vac between adjacent poles
    • 3-Position

    Used * No longer available for export
    MFR: Kraus & Naimer
    Made in Austria
    SKU: C10-600-12-P


  2. 4M2156H Mallory-Grigsby Non-Shorting Phenolic RF Switch (NOS/NIB)

    4M2156H Mallory-Grigsby Non-Shorting Phenolic RF Switch (NOS/NIB)

    $44.91

    • Circuits: 5
    • Sections: 5
    • Positions: 2-6
    • 60° Indexing Ceramic Wafer

    New Old Stock * New In Box * No longer available for export
    MFR: Mallory & Company, Inc.
    SKU: 4M2156H

    Made in the USA

  3. 3S0T2E01 DB Products SMA Female RF Coaxial Switch 28VDC (Pull)

    3S0T2E01 DB Products SMA Female RF Coaxial Switch 28VDC (Pull)

    $184.91

    Clean Used * No longer available for export
    MFR: DB Products Inc.
    SKU: 3S0T2E01-P

    Made in the USA
  4. D2-213A1 Dynatech SPDT 28VDC BNC RF Coaxial Switch (Pull)

    D2-213A1 Dynatech SPDT 28VDC BNC RF Coaxial Switch (Pull)

    $49.91

    • Small dents in case

    Used * No longer available for export
    MFR: Dynatech
    SKU: D2-213A1-P

  5. 426H-730332-1 Dow Key Pulse Latching DC-1.6-1.7GHz TNC Female 5 Port Switch (Pull)

    426H-730332-1 Dow Key Pulse Latching DC-1.6-1.7GHz TNC Female 5 Port Switch (Pull)

    $39.91

    Dow-Key’s innovative and proven high reliability, superior RF performance, and low current/magnetic latch switches have played a part in hundreds of successful space missions since the 1970s

    Wiring diagram available upon purchase

    • VSWR: 1.45 Max
    • Isolation: 60dB
    • Insertion loss: 0.45dB Max
    • Voltage: 23.0-36.0 VDC
    • LMC #: 20067443P2

    CLean Used * No longer available for export
    MFR: Dow Key
    SKU: 426H-730332-1-P


  6. 260B-260442 DowKey DPDT 115VAC By-Pass Switch (NOS)

    260B-260442 DowKey DPDT 115VAC By-Pass Switch (NOS)

    $186.91

    Frequency    VSWR    Isolation    Ins. Loss    RF Power
        MHz           (max)     dB (min)    dB (max)   Watts (max)
        0-50           1.05           40             0.04          1,000
      50-100         1.08           35             0.05          1,000
    100-400         1.15           25             0.10      1,000-500
    400-1,000      1.20           18             0.15        500-350

    New Old Stock * No longer available for export
    MFR: DowKey
    SKU: 260B-260442

    Data Sheet

    Made in the USA

  7. 54000G Automatic Metal Products BNC Switch (Pull)

    54000G Automatic Metal Products BNC Switch (Pull)

    $19.91

    • Similar to Amphenol 315-10002-3

    Used * No longer available for export
    MFR: Automatic Metal Products Corporation
    SKU: 54000G-P

    Made in the USA

  8. CDS0671 Daico GaAs SP2T Switch (Pull)

    CDS0671 Daico GaAs SP2T Switch (Pull)

    $39.91

    • Frequency: 10-2000MHz
    • Impedance: 50 Ohms
    • 20 nSec Switching Speed

    Used * No longer available for export
    MFR: Daico Industries
    SKU: CDS0671-P

    Made in the USA
  9. NWG18 Clarostat 3A 125VAC Switch (NOS/NIB)

    NWG18 Clarostat 3A 125VAC Switch (NOS/NIB)

    $54.91

    • 3 Amp 125VAC
    • 1/2 Amp 125VDC

    New Old Stock * New In Box * No longer available for export
    MFR: Clarostat
    SKU: NWG18


  10. 850A Barker & Williamson Band Switching Pi-Network Inductor (NOS)

    850A Barker & Williamson Band Switching Pi-Network Inductor (NOS)

    $299.91

    • Frequency Coverage: 80-40-20-15-10 Meter Amateur Bands
    • Power rating: 1Kw under Amplitude Modulation Conditions
    •                       2Kw PEP CW and SSB Conditions
    • Plate Voltage: Maximum 4000 Volts

    New Old Stock * No longer available for export
    MRF: Barker & Williamson
    SKU: 850A-BW

    Data Sheet

    Made in the USA

Items 21 to 30 of 117 total
