Coax Switches

• With Auxiliary Contacts

Used * No longer available for export
MFR: Advanced Electric and Relay Company
SKU: CB1C2C6VD-P

• Early version
• Frequency: 500MHz
• Terminal Type: 2 tab, solder lug and 3 recepticale, coaxial

Clean Used * No longer available for export
MFR: Dow-Key
SKU: DK-137-P

These medium size, light-weight relays are designed and manufactured with gold plated RF contacts and silver plated outer conductors which give good RF performance to 1 GHz.

• Isolation: greater than 30dB
• Insertion loss: less than 0.15dB

New Old Stock * No longer available for export
MFR: Dow-Key
SKU: 77-260232

Dow-Key’s innovative and proven high reliability, superior RF performance, and low current/magnetic latch SPDT switches have played a part in hundreds of successful space missions since the 1970s

• VSWR: 1.45 Max
• Isolation: 60dB
• Power: 24 W CW
• LMC #: 20067443P2

New Old Stock * No longer available for export
MFR: Dow Key
SKU: 426H-730332-1

Missing Knob
Dow-Key Series 78 selector switches are conservatively rated 1000w @ 50 MHz to 450w @ 450 MHz and 60 dB minimum isolation. Dow-Key quality, a good choice for the station.
Used * No longer available for export
MFR: Dow-Key, USA
SKU: 78-0404-NO-KNOB-P

Size: 1.75" Wide x 0.75" thick x 2.0" High
Used * No longer available for export
MFR: Teledyne Microwave
NSN # 5930-01-097-1099
SKU: CS38S13-P

The DowKey 60 Series coaxial relays are ruggedly constructed and designed for operation to a maximum power level of 1 kilowatt.
Coil Voltage: 220vac
New Old Stock * No longer available for export
MFR: Dow-Key Company
SKU: 60--2704

This 60 Series is a patented, high isolation option (“G” option) for transmit-receive applications. This option leaves the unused input open, and increases the isolation on the N/C connector to 85 dB at frequencies up to 500 MHz. This option reduces the maximum power rating of the N/C connector to 20 Watts, and will increase the VSWR of this terminal above approximately 400 MHz.
Designed for operation to a maximum power level of 1 kilowatt.
Coil Voltage: 115vac

Used * No longer available for export
MFR: Dow-Key Company
SKU: 60-262842

See Data Sheet for more information

The DowKey 60 Series coaxial relays are ruggedly constructed and designed for operation to a maximum power level of 1 kilowatt.
Coil Voltage: 115vac
Coil Current: 12 VDC - 250mA
                      28VDC - 108mA
Operate Time: 20 mS Maximum
Mechanical Life, Cycles: 1 x 10⁶ minimum
Not recommended for applications above 300 MHz

New Old Stock * No longer available for export
MFR: Dow-Key Company
SKU: 60-260442

See Data Sheet for more information
