Low Voltage Transformers

Low Voltage Transformers

Ideal transformers for tube filament or DC power supplies.
Primary Input Voltage 117vac
Output Voltage 12 VCT, 24 VCT, 48 VCT with center Tap
Solder Lug/Push-on Terminals
Class A Rated @105 degrees C
1,000 Volt Hi-Pot Tested.


Part #Rated Output Voltage.Current RatingFrame SizeMounting Hole
Center to Center
Overall Thickness/Width
(inches)(Excluding Mounting Tabs)
Height.
671121 12 vac 0.5 amp
EI-41x16.5 2.07"
 1.37 x 1.69
1.41"
671122 12 vac 1 amp EI-48x20B 2.36" 1.57 x 1.96
1.67"
671123 12 vac 1.5 amp EI-57x19A 2.79"

1.73 x 2.32

2.0"
671124 12 vac 2 amp EI-57x25B 2.79" 1.95 x 2.32
2.0"
671125 12 vac 2.5 amp EI-66x25B 3.14" 2.12 x 2.67
2.28"
671241 24 vac 0.5 amp EI-48x20B 2.36" 1.57 x 1.96
1.67"
671242 24 vac 1 amp EI-57x25B 2.79" 1.95 x 2.32
2.0"
671243 24 vac 1.5 amp EI-66x30 3.14" 2.29 x 2.67
2.28"
671244 24 vac 4 amp EI-76x30 3.62" 2.42 x 3.1
2.65"
671245 24 vac 2.5 amp EI-76x35A 3.62" x 2 rows in 0.72" pitch
2.64 x 3.1
2.65"
671483 48 vac 1.5 amp EI-76x40B 3.62" x 2 rows in 0.72" pitch 2.84 x 3.1
2.65"

List  Grid

per page
Set Descending Direction
  1. 20926  Transformer, 24vac, 2.7amp, Primary 120vac, Basler

    20926 Transformer, 24vac, 2.7amp, Primary 120vac, Basler

    $9.95

    20926  Transformer, 24vac, 2.7amp, Primary 120vac, 65 va, MFR: Basler Electric

  2. 671121 Low voltage transformer, 117VAC/60cps 12.6vct, 0.5 amp, (67-1121), CES

    671121 Low voltage transformer, 117VAC/60cps 12.6vct, 0.5 amp, (67-1121), CES

    671121 Low voltage transformer, 117vac primary voltage, secondary voltage 12vac with center tap, 117VAC/60cps 12.6vct, 0.5 amp, (67-1121), MFR: CES



  3. 671122  Low voltage transformer, 117VAC/60cps 12.6vct, 1 amp, (67-1122) CES

    671122 Low voltage transformer, 117VAC/60cps 12.6vct, 1 amp, (67-1122) CES

    671122 Low voltage transformer, 117vac primary voltage, secondary voltage 12vac with center tap, 117VAC/60cps, 12.6vct, 1 amp, (67-1122), MFR: CES



  4. 671123  Low voltage transformer, 117VAC/60cps 12.6vct, 1.5 amp, (67-1123) CES

    671123 Low voltage transformer, 117VAC/60cps 12.6vct, 1.5 amp, (67-1123) CES

    671123 Low voltage transformer, 117vac primary voltage, secondary voltage 12vac with center tap, 117VAC/60cps, 12.6vct, 1.5 amp, (67-1123), MFR: CES



  5. 671124  Low voltage transformer, 117VAC/60cps 12.6vct, 2 amp, (67-1124), CES

    671124 Low voltage transformer, 117VAC/60cps 12.6vct, 2 amp, (67-1124), CES

    671124  Low voltage transformer, 117VAC/60cps 12.6vct, 2 amp, (67-1124), MFR: CES



  6. 671125  Low voltage transformer, 117VAC/60cps 12.6vct, 2.5 amp, (67-1125), CES

    671125 Low voltage transformer, 117VAC/60cps 12.6vct, 2.5 amp, (67-1125), CES

    671125 Low voltage transformer, 117vac primary voltage, secondary voltage 12vac with center tap, 117VAC/60cps, 12.6vct, 2.5 amp, (67-1125), MFR: CES

  7. 671241 Low voltage transformer, 117VAC/60cps 24vct, 0.5 amp, (67-1241) CES

    671241 Low voltage transformer, 117VAC/60cps 24vct, 0.5 amp, (67-1241) CES

    671241 Low voltage transformer, 117vac primary voltage, secondary voltage 24vac with center tap. 117VAC/60cps 24vct, 0.5 amp, MFR: CES

  8. 671242  Low voltage transformer, 117VAC/60cps 24vct, 1 amp, (67-1242) CES

    671242 Low voltage transformer, 117VAC/60cps 24vct, 1 amp, (67-1242) CES

    671242 Low voltage transformer, 117vac primary voltage, secondary voltage 24vac with center tap, 117VAC/60cps 24vct, 1 amp, (67-1242), MFR: CES

  9. 671243  Low voltage transformer, 117VAC/60cps 24vct, 1.5 amp, (67-1243) CES

    671243 Low voltage transformer, 117VAC/60cps 24vct, 1.5 amp, (67-1243) CES

    671243 Low voltage transformer, 117vac primary voltage, secondary voltage 24vac with center tap, 117VAC/60cps 24vct, 1.5 amp, (67-1243), MFR: CES

  10. 671244  Low voltage transformer, 117VAC/60cps 24vct, 2 amp, (67-1244) CES

    671244 Low voltage transformer, 117VAC/60cps 24vct, 2 amp, (67-1244) CES

    671244 Low voltage transformer, 117vac primary voltage, secondary voltage 24vac with center tap, 117VAC/60cps 24vct, 2 amp, (67-1244), MFR: CES

Items 1 to 10 of 14 total
