Low Voltage Transformers
Low Voltage Transformers
Ideal transformers for tube filament or DC power supplies.
Primary Input Voltage 117vac
Output Voltage 12 VCT, 24 VCT, 48 VCT with center Tap
Solder Lug/Push-on Terminals
Class A Rated @105 degrees C
1,000 Volt Hi-Pot Tested.
| Part # | Rated Output Voltage | Current Rating | Frame Size | Mounting Hole Center to Center |
Overall Thickness/Width (inches)(Excluding Mounting Tabs) |
Height |
|---|---|---|---|---|---|---|
| 671121 | 12 vac | 0.5 amp | EI-41x16.5 | 2.07" | 1.37 x 1.69 | 1.41" |
| 671122 | 12 vac | 1 amp | EI-48x20B | 2.36" | 1.57 x 1.96 | 1.67" |
| 671123 | 12 vac | 1.5 amp | EI-57x19A | 2.79" | 1.73 x 2.32 | 2.0" |
| 671124 | 12 vac | 2 amp | EI-57x25B | 2.79" | 1.95 x 2.32 | 2.0" |
| 671125 | 12 vac | 2.5 amp | EI-66x25B | 3.14" | 2.12 x 2.67 | 2.28" |
| 671241 | 24 vac | 0.5 amp | EI-48x20B | 2.36" | 1.57 x 1.96 | 1.67" |
| 671242 | 24 vac | 1 amp | EI-57x25B | 2.79" | 1.95 x 2.32 | 2.0" |
| 671243 | 24 vac | 1.5 amp | EI-66x30 | 3.14" | 2.29 x 2.67 | 2.28" |
| 671244 | 24 vac | 4 amp | EI-76x30 | 3.62" | 2.42 x 3.1 | 2.65" |
| 671245 | 24 vac | 2.5 amp | EI-76x35A | 3.62" x 2 rows in 0.72" pitch | 2.64 x 3.1 | 2.65" |
| 671483 | 48 vac | 1.5 amp | EI-76x40B | 3.62" x 2 rows in 0.72" pitch | 2.84 x 3.1 | 2.65" |
671122 Low voltage transformer, 117VAC/60cps 12.6vct, 1 amp, (67-1122) CES
In Stock
671122 Low voltage transformer, 117vac primary voltage, secondary voltage 12vac with center tap, 117VAC/60cps, 12.6vct, 1 amp, (67-1122), MFR: CES
Add to Cart
671121 Low Voltage 6.3V Transformer 12 VCT 0.5 Amp (67-1121) CES
In Stock
671121, 6.3 Low voltage Transformer 117 VAC Primary Voltage.
Secondary Voltage 12 VAC with center tap. 117VAC/60cps 12.6vct, 0.5 amp, (67-1121)
MFR: Coast Electronic Supply
SKU: 671121
Add to Cart
671123 Low voltage transformer, 117VAC/60cps 12.6vct, 1.5 amp, (67-1123) CES
In Stock
671123 Low voltage transformer, 117vac primary voltage, secondary voltage 12vac with center tap, 117VAC/60cps, 12.6vct, 1.5 amp, (67-1123), MFR: CES
Add to Cart
