165V12 Transformer, 12vct 20a

165V12 Transformer, 12vct 20a

Be the first to review this product

In Stock

Quick Overview

165V12 Transformer, 12vct 20a


252 Secondary (R.M.S.) VAC 12.6 C.T Amps 20 Dim Ref. H12 Key Features Primary 115 VAC, 60 Hz. All secondaries center tapped (C.T.), VAC (RMS) Open style, 4 hole frame chassis mount. Minimum 6" long leads or copper tabs with holes. Dual bobbin design - no electrostatic shield required Class B insulation (130 degrees, C). Hi-Pot test of 2,000V RMS UL listed (# E207860) Type 3AHCSA certified (# LR209651)

Product Attachments

View File165 Series Transformers    Size: (308.92 KB)
