RF Parts Company ~ Coaxial Cable and Coax Switches

Coaxial Cable
• Minimum Order: $25.00 in Parts
• No returns on custom cut lengths..

Coax Cable

Deposit or prepayment (Visa, MC, check with order)
may be required on cable orders where shipping weight is significant.

Times LMR Cable
Teflon Cable
Belden & Similar Quality Cable

Preassembled Coax
Cable Accessories

Specifications & Guides

to cable groups & plating

Times LMR descriptions & uses

Times Microwave Communication Cable
Pricing & Information

Cable Part No.	Data Sheet	Description				Price per ft.¹
Cable Part No.	Data Sheet	Ohms	Mfg.	Dia.	Notes	10 - 49 ft.	50-199 ft.	200-499 ft.	500-999 ft.
LMR100		50	Times Microwave	0.110	Flexible low loss Coax, Solid Ctr Conductor	$ .64	$ .56	$ .52	$ .47
LMR195		50	Times Microwave	0.195	Flexible low loss Coax, Solid Ctr Conductor	.68	.58	.52	.47
68999#		50	Times Microwave	0.195	Teflon Coax, Solid Ctr Conductor	1.65	1.50	1.40	1.25
LMR200*		50	Times Microwave	0.200	Flexible low loss Coax, Solid Ctr Conductor	.70	.60	.58	.55
LMR240		50	Times Microwave	0.240	Low loss Coax, Solid Ctr Conductor	.85	.79	.71	.65
RFP240 #		50	RF Parts	0.240	Low loss Coax, Solid Ctr Conductor	Call	Call	Call	Call
LMR240DB		50	Times Microwave	0.240	Low loss Coax, Direct Burial, Solid Ctr Conductor	.90	.80	.72	.77
LMR240FR		50	Times Microwave	0.240	Low loss Coax, Fire Retardant, Solid Ctr Conductor	1.25	1.10	.95	.95
LMR240UF		50	Times Microwave	0.240	Flexible low loss Coax, Stranded Ctr Conductor	.98	.91	.82	.76
LMR240-75		75	Times Microwave	0.240	Low loss Coax, Solid Ctr Conductor	.89	.82	.77	.76
LMR400		50	Times Microwave	0.405	Low loss Coax, Solid Ctr Conductor	.89	.87	.86	.79
LMR400LLPL		50	Times Microwave	0.405	Low loss Coax, Plenum Rated, Solid Ctr Conductor	5.25	4.95	4.70	4.40
LMR400DB		50	Times Microwave	0.405	Low loss Coax, Direct Burial, Solid Ctr Conductor	1.00	.98	.96	.93
LMR400FR		50	Times Microwave	0.405	Low loss Coax, Fire Retardant, Solid Ctr Conductor	2.25	1.80	1.60	1.40
LMR400UF		50	Times Microwave	0.405	Flexible low loss Coax, Stranded Ctr Conductor	1.27	1.19	1.15	1.12
LMR400-75		75	Times Microwave	0.405	Low loss Coax, Solid Ctr Conductor	1.25	1.12	1.06	.99
LMR600		50	Times Microwave	0.590	Low loss Coax, Solid Ctr Conductor	1.97	1.79	1.70	1.60
LMR600LLPL*		50	Times Microwave	0.590	Low loss Coax, Plenum Rated, Solid Ctr Conductor	10.50	9.95	9.35	8.75
LMR600DB		50	Times Microwave	0.590	Low loss Coax, Direct burial, Solid Ctr Conductor	2.90	2.58	2.52	2.25
LMR600UF		50	Times Microwave	0.590	Flexible low loss Coax, Stranded Ctr Conductor	3.25	2.70	2.60	2.50
LMR900DB*, 1		50	Times Microwave	0.870	Low loss Coax, Direct burial, Solid Ctr Conductor	6.50	6.20	5.60	5.10
LMR900FR*, 1		50	Times Microwave	0.890	Low loss Coax, Fire Retardant, Solid Ctr Conductor	8.75	8.25	7.60	Call
* Special Order # Limited Supply 1 There will be a $15.00 cutting charge on lengths less than 200 feet.

Call for quote on LMR1200 and LMR1700.

Coaxial Cable \| Coax Accessories \| Connectors \| Adapters \| Preassembled Coax \| Coax Specifications \| Heliax Cable
Standard & Teflon Communication Cable Pricing & Information
Cable Part No.	Description				Price per ft.¹
Cable Part No.	Ohms	Mfg.	Dia.	Notes	10 - 49 ft.	50-199 ft.	200-499 ft.	500-999 ft.
50 Ohms
RG58U-BEL	50	Belden	0.195	Coax, Solid Ctr Conductor	.33	.27	.25	.23
RG58AU-BEL	50	Belden	0.195	Stranded Ctr Conductor	.33	.27	.25	.23
RG8X-BEL	50	Belden	0.240	Flexible Coax, Stranded Ctr Conductor	.39	.36	.32	.28
RG8X-BEL-WH	50	Belden	0.240	Flexible Coax, Stranded Ctr Conductor, White, Marine	.39	.36	.32	.28
RG142B/U	50	Belden	0.195	TEFLON Coax, Solid Ctr Conductor MIL-SPEC M17/158-83242	2.40	2.25	2.15	2.00
RG142B/U-RFP	50	RF Parts/ Harbour Ind.	0.195	TEFLON Coax, Solid Ctr Conductor	1.95	1.80	1.70	1.55
RG174/U	50	Victor	0.110	Flexible Coax, Stranded Ctr Conductor	.30	.26	.23	.21
RG213/U	50	Belden	0.405	Flexible Coax, Stranded Ctr Conductor	1.10	.95	.88	.84
RG214/U#	50	Advanced Digital	0.405	Flexible Coax, Double shield/stranded Ctr Conductor	1.95	1.75	1.60	1.45
RG214MILC17	50	Belden	0.405	Flexible Coax, Double shield/stranded Ctr Conductor MIL-SPEC MILC17/8268	3.75	3.45	3.30	3.00
RG218/U	50	Consolidated	0.88	Flexible Coax, Solid Ctr Conductor	6.50	6.25	5.85	5.35
RG223	50	Coleman	0.216	TEFLON Coax, Double Shield, Solid Ctr Conductor MIL-SPEC M17/84-RG223/8422	2.25	2.15	2.00	1.95
RG316	50	Harbour Ind.	0.110	Flexible TEFLON Coax, Clear Jacket, Stranded Ctr Conductor.	1.25	1.15	1.05	Call
RG316B	50	Harbour Ind.	0.110	Flexible TEFLON Coax, Black Jacket, Stranded Ctr Conductor.	1.15	1.05	.95	Call
RG393#	50	Times Microwave	0.400	Flexible TEFLON Coax, Stranded Ctr Conductor.	Call	Call	Call	Call
RG400	50	Tensolite	0.195	TEFLON Coax, Solid Ctr Conductor, MIL-SPEC M17/128	3.95	3.75	3.45	3.15
9203	50	Belden	0.195	Flexible Coax, Stranded Ctr Conductor, MIL-SPEC/RG58/U	.80	.72	.68	.64
9913					See LMR400
9913F7					See LMR400UF
RG217/U					See LMR600UF
75 Ohms
LMR240-75	75	Times Microwave	0.240	Flexible low loss Coax, Solid Ctr Conductor	.89	.82	.77	.76
LMR400-75	75	Times Microwave	0.405	Flexible low loss Coax, Solid Ctr Conductor	1.25	1.12	1.06	.99
RG11A/U#	75	Belden	0.412	Flexible Coax, Stranded Ctr Conductor 8213	1.65	1.55	.145	1.35
RG59/U	75	Belden	0.237	Flexible Coax, Solid Ctr Conductor 9104	.33	.27	.24	.23
RG6/U	75	Belden	0.298	Flexible Coax, Solid Ctr Conductor 1189A/1	.33	.28	.25	.22
RG179B/U#	75		0.100	Flexible TEFLON Coax, Stranded Ctr Conductor	1.75	1.50	1.35	1.25
RG179MILM17	75	Thermax	0.100	Flexible TEFLON Coax, Stranded Ctr Conductor MIL-SPEC M17/94	2.00	1.85	-	-
95 Ohms
RG180/U#	95	Tensolite	0.141	Flexible TEFLON Coax, Stranded Ctr Conductor MIL-SPEC M17/90	4.50	4.00	3.55	3.25
* Special Order # Limited Supply

Connector Installation: add $7.00 per connector for cable with a diameter of .405 or smaller,
anything above .405 is $15.00 per connector.
