Vacuum Variable

Vacuum Variable Capacitor, 8-250pf, 15kv Peak / 9KV,

MFR: Comet (NOS) No longer available for Export

SKU: CV1C-250FN/15

Capacitance:  12-500 pf
Voltage Rating: 7.5 kv
Current Rating: 100 Amps RMS (max)

Used
MFR: Jennings
SKU: CSVF-500-0107-P

• With Gear Drive system and mounting bracket.
• Capacitance: 10-1000 pf
• Voltage Rating: 15 kv Test; 9 kv Working

Used
MFR: Jennings
SKU: CVDG-1000-15N808-P

CV05C-1000PEN/5  Ceramic, Variable, Vacuum Capacitor, Basic Con Series , 50-1000pf, 5kv/3kv, (Round Slotted Shaft)
Used clean * No longer available for export
MFR: Comet
SKU: CV05C-1000PEN/5

Rated Capacitance: 7-1000 pf
Peak Voltage: 3 KV
NSN #: 5910-01-217-8867

MFR: Jennings
SKU: UCSL-1000-3S

Capacitance:  25-700 pf
Voltage Rating:  12 KVp
Current Rating:  65 amp (Estimated)

Used
MFR: Jennings
SKU: UCSX-700-12-P

Capacitance:  25-700 pf
Voltage Rating:  12.5 KVp
Current Rating:  65 amp (Estimated)

Used * These Units are originally 15kv units but test slightly lower than spec and are being sold as 12.5kv units
MFR: Jennings
SKU: UCSX-700-12-GEAR-P

 Vacuum Variable Assembly with Jennings UCSL-1000 capacitor rated at 7-1000pf / 3kv.

Used
MFR: Jennnings Radio
SKU: UCSL1000-ASSEM-P

• Variable capacitor motor drive assembly removed from equipment.
• Comes with Jennings UCSL-1000 vacuum variable rated 7-1000pf at 3kv.
• Assembly has Gear driven motor drive mounted on aluminun plate and comes with DC Motor from Globe Industries (Part # C-25A-511).
• Motor spec:  27.5 volts nom., 6 amps nom., 1/100 hp at 15000 rpm min.
• Assembly is 8 inch long x 3 inch wide x 7 inch high.
• UCSL-1000 is mounted on 4 NS5W0212 ceramic standoff insulators.

Used
MFR: Jennings
SKU: UCSL-1000-3D345 Assembly-P

Removed from military equipment
