DEM2318 Module PCB, Bi-Polar Modules

DEM2318 Module PCB, Bi-Polar Modules

Be the first to review this product

In Stock
$15.00
OR

Quick Overview

DEM2318 Module PCB, Bi-Polar Modules

Module PCB board for Bi-Polar style Power Modules

Details

Module PCB board for Bi-Polar style Power Modules

pc module board      For Mitsubishi, Toshiba, and other RF Power Modules with case style H3 (M57727, M57735, M57745, M57762, SAU4, etc.). Easily modified to use H2 case styles.

     Includes application notes for module frequencies 50-1300 MHz. Provision for placement of bypass capacitors and choke coils. Connections for MC7809 voltage regulator if required. Double-sided FR4 board with plated-thru holes.

Size 4.1"x1.0". (Module Data Sheet recommended.)

Part #: DEM2318      •     $15.00 ea.
