Relays
Please choose from the following RELAY Sub-Catagory choices:
|
||
RELAY SOCKETS |
|
|
|
-
60-220242 Dow-Key 12vdc SPDT BNC Switch (Pull)
$59.91 -
-
DK2-60B Dow Key DPDT Relay (NOS)
$180.91 -
H-17 Kilovac Vacuum Relay 26.5VDC 120 Ω 30A SPDT Threaded Mount (Pull)
$985.91The H-17 SPDT Vacuum Relay will isolate 12 kV at 32 MHz. The Tungsten contacts are suitable for power switching low current loads.
Meets requirements of MIL-R-83725.Coil Data
Nominal Volts DC: 12 Vdc 26.5 Vdc 115 Vdc
Pickup, Maximum: 8 Vdc 16 Vdc 80 Vdc
Dropout: .5-5 Vdc 1-10 Vdc 5-50 Vdc
Coil Resistance (±10%) 120 ΩUsed * Clean Condition * No longer available for export
MRF: Kilovac Made in USA
SKU: H-17Made in the USA -
RP101F4903D21B20 Jennings Vacuum Contactor (Pull)
$794.95 -
RP103F4304D23B20 Jennings 80KV Peak Vacuum Relay (Pull)
$794.95 -
56-220202 Dow-Key 12v SPDT BNC Coax Relay 150w CW Female (3 Connectors) (NOS)
$149.95 -
315-010002-3 Amphenol Coax Relay SPDT 26vdc (3) BNC Female (Pull)
$49.95 -
360-11892-13 Amphenol Coax Relay SPDT (3) TNC Female Connectors 26V DC, DC-6 GHz Dynaform Series (Pull)
$79.95 -
260 Dow-Key 24vdc DPDT BNC Female Coaxial Relay (Pull)
$140.91
