Relays
Please choose from the following RELAY Sub-Catagory choices:
|
|
COAX RELAYS (VARIOUS MANUFACTURERS)
|
|
|
|
|
|
|
|
|
|
| RELAY SOCKETS
|
|
|
|
|
|
-
71-230301 Dow Key 6PST Custom Remote Activated TNC Switch with 7-Pin Input Connector (Pull)
$99.91 -
8762B Agilent SPDT SMA Coaxial Switch DC-18GHz 50 Ohm (Pull)
$69.91 -
-
-
MA7530-S030 Microwave Associates SPDT SMA Female Coaxial Relay 28vdc (Pull)
$23.91 -
-
B5F-330100/P Charter Engineering SPDT Coaxial Relay 24VDC (Pull)
$119.91Switch Series: B5 - SPDT Type N
Actuator: Failsafe
Frequency Bandwidth: DC - 12.4 GHz
Voltage: 20 - 30 VDC (24.0 V nominal)
Power Interface: Solder Terminal (Top of Switch)These relays were pulled from equipment, have cosmetic dents, have been tested and meet specifications.
Used * No longer available for export
MFR: Charter Engineering
SKU: B5F-330100/P-DENT-P -
B5F-330100/P Charter Engineering SPDT Coaxial Relay 24VDC (Pull)
$129.91Switch Series: B5 - SPDT Type N
Actuator: Failsafe
Frequency Bandwidth: DC - 12.4 GHz
Voltage: 20 - 30 VDC (24.0 V nominal)
Common Polarity: Not required
Power Interface: Solder Terminal (Top of Switch)
Options: No other options required
Intermodulation: Standard Switch
Special Options: High Temp, High Power ConnectorThese relays were pulled from equipment, have a scuffed suface, have been tested and meet specifications.
Used * No longer available for export
MFR: Charter Engineering
SKU: B5F-330100/P-SCUFF-P -
H-17 Kilovac Vacuum Relay 26.5VDC 120 Ω 30A SPDT Threaded Mount (Pull)
$985.91The H-17 SPDT Vacuum Relay will isolate 12 kV at 32 MHz. The Tungsten contacts are suitable for power switching low current loads.
Meets requirements of MIL-R-83725.Coil Data
Nominal Volts DC: 12 Vdc 26.5 Vdc 115 Vdc
Pickup, Maximum: 8 Vdc 16 Vdc 80 Vdc
Dropout: .5-5 Vdc 1-10 Vdc 5-50 Vdc
Coil Resistance (±10%) 120 ΩUsed * Clean Condition * No longer available for export
MRF: Kilovac Made in USA
SKU: H-17Made in the USA -
401-420832A-2 Dow-Key Microwave SPDT Coaxial Relay (NOS)
$89.91Switch Type: Nontransfer
Operating Temp Rang: -55.0/+95.0 deg celsius
Coaxial Connector Series Designation: SMA
Connector End Design: Female
Maximum Operating Altitude Rating: 50000.0 feet
Switch Return Mechanism Type: Latching
RF Maximum Voltage Rating: 350.0 volts rms
Coupling Position Quantity: 3
Precious Material and Location: Contacts gold
Precious Material: GOLD
Supplementary Features: Coil voltage 20.0 min; switching time 20 msec at 20 vdc; driver
Terminal Type and Quantity: 8 solder stud
New Old Stock * No longer available for export
Manufacturer: Dow-Key Microwave
NSN number: 5985-01-293-4065
SKU: 401-420832A-2Made in the USA
