Relays
Please choose from the following RELAY Sub-Catagory choices:
|
||
RELAY SOCKETS |
|
|
|
-
810C00100 Transco Coax Relay SPDT 28vdc SMA Female (Pull)
$64.91 -
402-123 Dow-Key 12vdc Latching Switch Type N Female (NOS)
$499.91Out of stock
-
-
-
DK2-60B Dow Key DPDT Relay (NOS)
$180.91 -
H-17 Kilovac Vacuum Relay 26.5VDC 120 Ω 30A SPDT Threaded Mount (Pull)
$985.91The H-17 SPDT Vacuum Relay will isolate 12 kV at 32 MHz. The Tungsten contacts are suitable for power switching low current loads.
Meets requirements of MIL-R-83725.Coil Data
Nominal Volts DC: 12 Vdc 26.5 Vdc 115 Vdc
Pickup, Maximum: 8 Vdc 16 Vdc 80 Vdc
Dropout: .5-5 Vdc 1-10 Vdc 5-50 Vdc
Coil Resistance (±10%) 120 ΩUsed * Clean Condition * No longer available for export
MRF: Kilovac Made in USA
SKU: H-17Made in the USA -
63-103 Dow-Key 12vdc SPDT Failsafe Coax Relay (Pull)
$62.91The Dow-Key 63 Series SPDT Failsafe Relay provides an enclosed actuator for
use in environments where dust or moisture may be encountered.Connector Type: N
Operating Voltage: 12Vdc, 28 Vdc
Coil Current (Nominal): 12Vdc 255mA
28Vdc 112mA
Operate Time: 20 Ms maximum
Operating Temperature: -25oC to +65oC
Mechanical Life, Cycles: 1 x 106 minimum
Nominal Weight: 6.0 oz., (170g.)Used * No longer available for export
MFR: Dow-Key Microwave
SKU: 63-103Made in the USA -
RF43-26N909 Jennings Vacuum Relay 26.5 VDC 12 AMP 47 Ohm 7kv 9kv Peak SPST (NOS)
$79.95
