MRF/SRF/M Series

Designed for wideband large signal amplifier and oscillator applications  Up to 400 MHz range, in single-ended configuration  N–Channel enhancement mode

• Guaranteed 28 volt, 150 MHz performance  Output power = 15 watts  Narrowband gain = 16 dB (Typ.)  Efficiency = 60% (Typ.)
• Small– and large–signal characterization
• 100% tested for load mismatch at all phase angles with 30:1 VSWR
• Excellent thermal stability, ideally suited for Cass A operation
• Facilitates manual gain control, ALC and modulation techniques

New Old Stock * No longer available for export
MFR: Motorola
SKU: MRF136-MP

Designed for wideband large signal amplifier and oscillator applications  Up to 400 MHz range, in single-ended configuration  N–Channel enhancement mode

New Old Stock * No longer available for export
MFR: Motorola
SKU: MRF136-MOT

Designed for broadband commercial and military applications using push pull circuits at frequencies to 500 MHz. The high power, high gain and broadband performance of these devices makes possible solid state transmitters for FM broadcast or TV channel frequency bands, N–Channel enhancement mode

New Old Stock * No longer available for export
MFR: Motorola
SKU: MRF176GV-MOT

The MRF151G MA/COM Transistor is an early version, produced with the Motorola die.

Designed for broadband commercial and military  applications at frequencies to 175 MHz. The high power, high gain and broadband performance of this device makes possible solid state transmitters for FM broadcast or TV channel frequency bands.

New Old Stock * No longer available for export
MFR: Motorola M/A-COM USA
SKU: MRF151G-MA-M

Designed primarily for wideband large–signal output and driver stages to 30 – 500 MHz, N–Channel enhancement mode MOSFET

MFR: M/A-COM
SKU: MRF166W-MA

Made with original Motorola Die

Designed primarily for wideband large–signal driver and predriver amplifier stages in 200–500 MHz frequency range.

• Guaranteed performance at 400 MHz, 28 Vdc
• Output power = 10 W
• Power gain = 12 dB min.
• Efficiency = 50% min.
• 100% tested for load mismatch at all phase angles with 30:1 VSWR
• Gold metallization system for high reliability
• Computer–controlled wirebonding gives consistent input Impedance

MRF: M/A-COM
SKU: MRF134-MA

Designed for wideband large signal amplifier and oscillator applications  Up to 400 MHz range, in single-ended configuration  N–Channel enhancement mode
.
• Guaranteed 28 volt, 150 MHz performance  Output power = 15 watts  Narrowband gain = 16 dB (Typ.)  Efficiency = 60% (Typ.)
• Small– and large–signal characterization
• 100% tested for load mismatch at all phase angles with 30:1 VSWR
• Excellent thermal stability, ideally suited for Cass A operation
• Facilitates manual gain control, ALC and modulation techniques

MFR: M/A-COM
SKU: MRF136-MA

Made with original Motorola Die

Designed for wideband large signal amplifier and oscillator applications  Up to 400 MHz range, in either single-ended or push-pull configuration. N–Channel enhancement mode

MFR: M/A-COM
SKU: MRF136Y-MA

Designed for wideband large signal output and drive stages Product Image  up to 400 MHz range.  N–Channel enhancement mode

• Guaranteed 28 V, 150 MHz performance  Output power = 30 W  Minimum gain = 13 dB  Efficiency — 60% (Typical)
• Small– and large–signal characterization
• Typical performance at 400 MHz, 28 Vdc, 30 W output = 7.7 dB gain
• 100% tested for load mismatch at all phase angles with 30:1 VSWR
• Low noise figure — 1.5 dB (typ.) at 1.0 A, 150 MHz
• Excellent thermal stability, ideally suited for Class A operation
• Facilitates manual gain control, ALC and modulation techniques

Limit, 10 per customer.

MFR: M/A-COM
